SparkEngine

Spark Engine is a 3D engine developed by Marc Guillen and Axel Alavedra during the Game Development grade at CITM-UPC Terrassa. The entire development has been supervised by the lecturer Ricard Pillosu.

The code is written in C++.

Authors

• Axel’s GitHub account: AxelAlavedra

Contribution

• Component info on Inspector.
• Quadtree.
• Render scene to texture and show on Scene Window.
• Scene window resizing with aspect ratio.
• Scene serialization. Load/Save scene with UI.
• Save mesh, texture and models to own file format.
• Module resources (meta files, reference counting, etc).
• Engine Start/Pause and state recovery.
• Time module.
• Resource Management.
• Resource Import settings.
• Skinning.
• Bones import and Skeleton attachment.
• Animation import.
• Animation import settings ( Creation of clips ).
• Animator Controller own file. Import/Save/Load of that file.

• Marc’s GitHub account: Marcgs96

Contribution

• Component info on Inspector.
• Quadtree.
• Camera Component.
• Frustum culling accelerated by Quadtree.
• Mouse picking accelerated by Quadtree.
• GameObject hierarchy system.
• Transform Component.
• ImGuizmo implementation.
• Game Panel that displays the view and projection of the main active camera.
• Module Camera3D.
• Animation time management and interpolation between keys.
• Blending between animation.
• Animator Controller state machine.
• Animator editor.

Main core sub-systems

• It has a hierarchy of gameObjects, each can have multiple components that define and complement them (transformation, mesh, material, animation, bone, camera).
• Can manipulate their transformation directly from the scene panel through the usage of a guizmo.
• Can freely add, remove and change parent and order of gameObjects into the hierarchy panel.
• It has a file and resource systems, to manage asset files, imort them and store them as binaries for easily usage.
• It is using a QuadTree to optimize frustum culling of static gameObjects.
• It has scene serialization of json files through rapidjson library.n any game engine an easy-to-use UI is a must and, thanks to the ImGui library, this was super fast an simple to implement. The way we did it was having a GUI module that works as a manager for all ImGui panels. To approach the Inspector panel, we implemented an OnEditor method at each component so, when a game object is selected, we draw its components on the Inspector.

Skeletal animation sub-system

Features

• It allows the user to import fbx files that contain animations using Assimp.
• The user can create clips of the imported animation and set the clip on loop.
• He can also create an asset called Animation Controller. A state machine that allows the user to create different states and transitions between them. He can create/modify the name/select a clip resource/Delete a state, and Create/Set the trigger/Set the blend value/Delete a transition.

System in-depth

• It reads animations and bones from a fbx file, then we link the bones to a mesh so we can modify it through skinning.
• Then, when a animator component is attached to a game object and a Animator Controller to the component, the object bones will be updated from the animation key values in each frame when we hit play.
• On update, every key frame for every bone, an update transform is called which interpolates the current key values with the next key values of every transform component (position, rotation, scale).
• At the end of the animation, if the clip is setted to loop it will start again.

• If theres a transition to another animation and the transition is triggered, both animation transforms will blend for smoother results.

• Editor gif

Imgur

• In-game gif

• Innovation Animation Controller editor gif

• Innovation Key viewer

• Innovation Manage clips gif

Video

Repository

• Organization’s Github: ProboxAM
• GitHub repository: SparkEngine

Tools used to develop the engine

• IDE: Microsoft Visual Studio 2017-2019
• External libraries:
  • SDL 2.0.10
  • OpenGL 4.6.0
  • Glew 2.1.0
  • Assimp 5.0.0
  • DevIL 1.8
  • ImGui 1.74 WIP
  • MathGeoLib 1.5
  • PCG Random Number Generator 0.98
  • JSON for modern C++ 3.7.0
  • PhysFS 3.0.1
